As Wi-Fi 7 (IEEE 802.11be) moves closer to real-world deployment, more device manufacturers are evaluating SoC solutions for next-generation wireless products. Among the most anticipated Wi-Fi 7 chipsets from Qualcomm are the IPQ9570 and IPQ5424. While both support the latest wireless standards, they differ significantly in architecture, performance, and target applications.
1. Core Specification Comparison
| Feature | IPQ9570 | IPQ5424 |
|---|---|---|
| Wi-Fi Support | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) |
| CPU | Quad-core ARM Cortex-A73 @ 2.2GHz | Quad-core ARM Cortex-A53 @ 1.5GHz |
| Process Node | 14nm | 14nm |
| Frequency Bands | 2.4GHz / 5GHz / 6GHz (Tri-band) | 2.4GHz / 5GHz / 6GHz (Tri-band) |
| Memory Support | DDR4 / DDR5 | DDR4 |
| Interfaces | 10G Ethernet, PCIe 3.0, USB 3.0 | 2.5G Ethernet, PCIe 3.0, USB 3.0 |
| Target Use Case | High-end enterprise APs, gateways, edge networking | Mid-to-high-end routers, mesh nodes |
| Expansion Capability | High | Moderate |
2. IPQ9570: Built for High-Performance Wireless Networks
The IPQ9570 is a flagship SoC in Qualcomm’s Networking Pro series, designed for high throughput, dense environments, and advanced routing performance.
Key Features:
-
Tri-band Wi-Fi 7 support (2.4G + 5G + 6G)
-
High-performance Cortex-A73 quad-core CPU at 2.2GHz
-
Supports multiple 10G Ethernet ports
-
Works with QCN9274/QCN6274 NICs for up to 8×8 MIMO configurations
Ideal Applications:
-
Enterprise-grade Wi-Fi 7 Access Points
-
Carrier-grade home gateways
-
Industrial/commercial repeaters
-
Outdoor CPE and edge computing gateways
3. IPQ5424: Performance-Cost Balanced Wi-Fi 7 Platform
The IPQ5424 is a more cost-effective Wi-Fi 7 SoC offering, ideal for performance-conscious designs without overcommitting on hardware resources.
Key Features:
-
Tri-band Wi-Fi 7 support for broad compatibility
-
Cortex-A53 quad-core CPU at 1.5GHz for energy-efficient computing
-
Supports 2.5G Ethernet and PCIe 3.0, fitting most mid-range network products
Ideal Applications:
-
Wi-Fi 7 home routers
-
Smart home hubs
-
Mesh network nodes
-
Embedded IoT edge devices
4. Side-by-Side Analysis
| Criteria | IPQ9570 | IPQ5424 |
|---|---|---|
| Processing Power | High (A73 @ 2.2GHz) | Moderate (A53 @ 1.5GHz) |
| Network Throughput | 10Gbps+ | 2.5Gbps |
| Power Consumption | Higher | Lower |
| Cost | Higher | Lower |
| Market Position | Enterprise, carrier, industrial | Consumer, prosumer, SMB |
The IPQ9570 targets demanding environments that require maximum performance and capacity. In contrast, the IPQ5424 offers a more accessible path to Wi-Fi 7 for mid-range products, balancing cost, power, and performance.
5. Conclusion
If your goal is to build high-performance Wi-Fi 7 networking solutions—such as enterprise APs or next-gen gateways—the IPQ9570 stands out with its CPU performance and I/O bandwidth. On the other hand, the IPQ5424 is ideal for manufacturers seeking a cost-optimized yet capable SoC for smart routers or mesh systems.
