Comparing Wi-Fi 6 Routerboards: Mikrotik L23UGSR-5HaxD2HaxD vs Wallys DR5018S

When it comes to deploying high-performance Wi-Fi 6 routerboards, both the Mikrotik L23UGSR-5HaxD2HaxD and the Wallys DR5018S offer impressive features tailored to diverse networking needs. Here’s a comprehensive comparison of these two powerful devices.

IPQ5010-IPQ5018

The IPQ5010 and IPQ5018 are advanced chipsets from Qualcomm, designed to enhance networking performance with the latest Wi-Fi 6 technology. The IPQ5010 features a dual-core ARM processor running at 800 MHz, while the IPQ5018 steps up the performance with a dual-core ARM 64-bit A53 processor operating at 1.0 GHz. Both chipsets support dual-band and tri-band configurations, allowing for efficient data handling across multiple channels.

Equipped with advanced features such as OFDMA and MU-MIMO, these chipsets enable seamless connectivity for numerous devices simultaneously, making them ideal for high-density environments like homes, offices, and public spaces. With robust Ethernet support and improved power efficiency, the IPQ5010 and IPQ5018 deliver reliable, high-speed internet connectivity, ensuring a superior user experience for gaming, streaming, and other bandwidth-intensive applications.

Mikrotik L23UGSR-5HaxD2HaxD

Hardware Specifications:

• Architecture: ARM

• CPU: IPQ-5010, dual-core at 800 MHz

• RAM: 256 MB

• Storage: 128 MB NAND

• Operating System: RouterOS v7

• Power Supply: Dual inputs (DC jack and PoE), 12–28V

Wireless Performance:

• 2.4 GHz:

• Max Data Rate: 574 Mbps

• Standards: 802.11b/g/n/ax

• Number of Chains: 2

• 5 GHz:

• Max Data Rate: 2400 Mbps

• Standards: 802.11a/n/ac/ax

• Number of Chains: 2

Mikrotik L23UGSR-5HaxD2HaxD

Networking Features:

• Ethernet Ports: 1 x 10/100/1000 Mbps

• SFP Ports: 1 (supports 2.5G)

• Peripherals: 1 Nano SIM slot, 1 MiniPCI-e slot, 1 USB 3.0 port

Durability:

• Operating Temperature: -40°C to 70°C

• MTBF: Approximately 100,000 hours at 25°C

Wallys DR5018S

Hardware Specifications:

• CPU: Qualcomm-Atheros IPQ5018, dual-core ARM 64-bit A53 @ 1.0 GHz

• RAM: 512 MB DDR3L

• Storage: 128 MB NAND, 8 MB Nor Flash

• Power Supply: 24V-48V (DC Jack) and Active PoE (802.3at/BT)

Wireless Performance:

• 2.4 GHz:

• Max Data Rate: 573 Mbps

• Configuration: 2×2

• 5 GHz:

• Max Data Rate: 2402 Mbps

• Configuration: 2×2

• 6 GHz:

• Max Data Rate: 2402 Mbps

• Configuration: 2×2

Networking Features:

• Ethernet Ports: 1 x 1Gbps and 1 x 2.5Gbps

• Additional Interfaces: USB 3.0, SGMII, UART

Wallys DR5018S IPQ5018

Durability:

• Operating Temperature: -40°C to 70°C

• Humidity Range: 5% to 95% (non-condensing)

Software Support:

• Compatible with OpenWiFi, OpenWrt, and Wallys original firmware.

Conclusion

Choosing between the Mikrotik L23UGSR-5HaxD2HaxD and the Wallys DR5018S depends on your specific networking requirements. The Mikrotik model is ideal for users needing a compact, feature-rich routerboard with dual SIM support. In contrast, the Wallys DR5018S excels in versatility and extensive Ethernet options, making it perfect for larger, more complex deployments.

Wallys DR5018S

For further inquiries about the Wallys DR5018S, please contact sales1@wallystech.com or visit our webpage at Wallys Tech.
