Wallys QCA9880 QCA9882 802.11ac 80MHz Dual Band miniPCIE card/FCC CE IC DR882 DR900VX DR600VX
In the realm of wireless networking, the choice of wifi card plays a crucial role in determining the performance and capabilities of networking devices. Wallys, offers network card intergrated with the QCA9880 and QCA9882 chipsets, which are known for their advanced features and exceptional performance. Let's delve into the key characteristics of these chipsets and understand how they contribute to the evolution of wireless networking.
QCA9880: Powering High-Speed Connectivity
The QCA9880 chipset, developed by Qualcomm-Atheros, is designed to deliver fast and reliable wireless connectivity. This chipset supports the IEEE 802.11ac standard, which provides significant improvements in speed, capacity, and overall network performance. With its advanced features, such as multiple input, multiple output (MIMO) technology and beamforming, the QCA9880 chipset enhances signal strength, range, and overall network efficiency. It enables devices to achieve data rates of up to 1.3Gbps, making it ideal for bandwidth-intensive applications, such as video streaming and online gaming. Additionally, the QCA9880 chipset ensures backward compatibility with previous Wi-Fi standards, allowing seamless integration with existing networks.
QCA9882: Enabling Enhanced Wireless Capabilities
The QCA9882 chipset, also developed by Qualcomm-Atheros, is designed to provide enhanced wireless capabilities for a wide range of applications. This chipset supports both the 2.4GHz and 5GHz frequency bands, enabling dual-band operation for improved network flexibility and reduced interference. With its support for 802.11ac technology, the QCA9882 chipset offers higher data transfer rates and improved network efficiency compared to previous Wi-Fi standards. It incorporates advanced features like spatial multiplexing, low-density parity check (LDPC) codes, and maximal ratio combining (MRC), enabling robust and reliable wireless connections. The QCA9882 chipset also supports dynamic frequency selection (DFS), which helps optimize channel selection and minimize interference from other wireless devices.
Here's a breakdown of the key features of each card:
DR882 (QCA9882):
Chipset: Atheros QCA9882
2×2 5G high-power radio card
Frequency range: 4.940GHz to 5.825GHz
2x 5G MMCX connectors
Bandwidth: 20MHz/40MHz/80MHz
Supports 802.11ac/an standards
RoHS compliant
DR600VX (QCA9880):
Chipset: Qualcomm-Atheros QCA9880
Output power: 2.4GHz max 24dBm, 5GHz max 23dBm
IEEE 802.11a/b/g/n compliant and backward compatible
2×2 MIMO technology, up to 867Mbps
Mini PCI Express edge connector
Frequency support: 4920MHz~4980MHz
RoHS compliant
Supports various technologies and IEEE standards (e.g., spatial multiplexing, LDPC codes, MRC, STBC, DFS)
FCC, CE certification
DR900VX (QCA9880):
Chipset: Qualcomm-Atheros QCA9880
Output power: 2.4GHz max 26dBm, 5GHz max 25dBm
IEEE 802.11a/b/g/n/ac compliant and backward compatible
3×3 MIMO technology, up to 1.3Gbps
Mini PCI Express edge connector
RoHS compliant
Supports various technologies and IEEE standards (e.g., spatial multiplexing, LDPC codes, MRC, STBC, DFS)
FCC, CE, and IC certification
These cards are designed for wireless networking applications and provide different specifications in terms of output power, MIMO technology, data rates, and frequency ranges. The certifications (FCC, CE, IC) indicate that the cards meet the regulatory requirements for electromagnetic compatibility and safety standards in the United States (FCC), European Union (CE), and Canada (IC).
For more information about the QCA9880 QCA9882 WIFI5 miniPCIE Card and its capabilities, please visit our website at https://www.wallystech.com/ or contact our sales team at sales1@wallystech.com. We eagerly await the opportunity to assist you in fulfilling your wireless connectivity needs.
