  • Exploring Wi-Fi 7 4×4 Qualcomm Triband Solutions

    Wi-Fi 7, also known as 802.11be, marks a significant leap forward in wireless networking technology, offering enhanced performance, higher throughput, and lower latency compared to its predecessors. With features like 320 MHz channel bandwidth, 4K-QAM modulation, and Multi-Link Operation (MLO), it is poised to deliver speeds up to 46 Gbps, ideal for the ever-increasing demands of modern networks.

    This article explores several Qualcomm-based Wi-Fi 7 4×4 triband solutions from Wallys Communications, highlighting their key features and applications.

    1. DR9574: Tri-Band Routerboard with Qualcomm IPQ9574

    • Overview: The DR9574 routerboard is equipped with the Qualcomm IPQ9574 chipset and features 4×4 MU-MIMO technology, offering robust performance across three bands (2.4 GHz, 5 GHz, and 6 GHz). It supports four M.2 slots, which provides significant flexibility for module integration and customization.

    • Specifications:

    • Chipset: Qualcomm IPQ9574 and QCN9274

    • Bands: Tri-band (2.4 GHz, 5 GHz, 6 GHz)

    • Ports: 2x 10G Ethernet and 4x 1G Ethernet ports

    • Applications: Suitable for high-performance networking applications such as routers, access points, and enterprise-level solutions, the DR9574 is designed for environments where both speed and reliability are critical.

    • Use Case: It is ideal for deployment in offices, large homes, or enterprise environments that demand simultaneous high-speed connections across multiple devices.

    More about DR9574

    2. DR9274 Series: Single-Band Wi-Fi 7 M.2 Modules

    • Overview: The DR9274 series consists of three single-band Wi-Fi 7 cards—each catering to a different frequency band (2.4 GHz, 5 GHz, and 6 GHz). These M.2 modules provide high-speed 4×4 MU-MIMO functionality, enabling better coverage and increased data throughput in densely populated environments.

    • Key Models:

    • DR9274-2G: Focuses on the 2.4 GHz band, which is ideal for devices requiring long-range connectivity with moderate data requirements.

    • DR9274-5G: Optimized for the 5 GHz band, offering a balance between range and speed, perfect for most modern devices.

    • DR9274-6G: Leverages the 6 GHz band, providing ultra-fast connectivity with minimal interference, designed for future-proofing wireless networks.

    • Specifications:

    • Chipset: Qualcomm QCN9274 and QCN6274

    • Form Factor: M.2 slot, ensuring easy integration into a wide range of devices.

    • 4×4 MU-MIMO: Delivers enhanced performance for demanding applications, such as streaming, gaming, and large file transfers.

    • Use Case: The DR9274 series is ideal for laptops, embedded systems, and other devices requiring high-performance wireless modules in specialized applications.

    More about DR9274-2G

    More about DR9274-5G

    More about DR9274-6G

    3. DR5332: Qualcomm IPQ5332 Dual-Band Routerboard

    • Overview: The DR5332 is a dual-band routerboard that comes with a Qualcomm IPQ5332 chipset, offering support for 2.4 GHz and 5 GHz bands. It is designed for network solutions that require fast, stable, and efficient connections.

    • Specifications:

    • Chipset: Qualcomm IPQ5332

    • Ports: 10G SFP for high-speed fiber connections, making it ideal for data-heavy applications.

    • Memory: 1 GB DDR4, enhancing performance for processing-intensive tasks.

    • Use Case: This model is well-suited for small- to medium-sized business environments, especially where high data throughput and fiber connectivity are crucial.

    More about DR5332

    Conclusion

    The Qualcomm Wi-Fi 7 4×4 triband solutions provide a comprehensive range of products tailored to meet the needs of high-performance networking applications. From single-band M.2 modules to advanced routerboards supporting multiple frequencies, Wallys’ lineup offers flexibility and scalability for various industries and use cases.

    Inquiry Contact:sales1@wallystech.com
