IPQ4019 IPQ4029 ,802.11AC 2×2 2.4G&5G
2×2 2.4Ghz&5G Support HTTPS Support all the modules of Quectel
The IPQ4019 was the industry’s first single-chip Wi-Fi system-on-chip (SoC) to bring Wave-2 802.11ac features to a variety of home and enterprise networking products. The highly-integrated, single-chip design combines dual-band 11ac, advanced Wi-Fi features and network processing in a variety of configurations for high-performance, power-efficient and cost-effective network infrastructure products.
The IPQ4029 was the industry’s first single-chip Wi-Fi system-on-chip (SoC) to bring Wave-2 802.11ac features to a variety of home and enterprise networking products. The highly-integrated, single-chip design combines dual-band 11ac, advanced Wi-Fi features and network processing in a variety of configurations for high-performance, power-efficient and cost-effective network infrastructure products.
MT7915/MT7975/IPQ6000/IPQ6018/IPQ6010/IPQ4019/IPQ4029/ipq4018/IPQ4028/IPQ8072/IPQ8072A/IPQ8074/IPQ8074A/QCN6024/QCN9074/QCN9072/QCN9024/IPQ5018/AR9223/QCA9880/QCA9882 /AR9582/AR9531/AR9344 /AX200NGW/ AP9342
With over 15 years of experience in wireless industry and penetrating market olfaction, Wallys has designed and manufactured many high quality and cost-effective routerboards and wireless network cards.
In the complex market, Wallys products stand out and are affirmed by partners. From 802.11 a – ax, Wallys always keeps up with the most cutting-edge wireless technology, aimed to help customers take the preemptive opportunities to occupy the market and lead a win -win cooperation.
BY:Wallys Communications (Suzhou ) Co., LTD
EMAIL:sales3@wallystech.com
1. DR40X9
https://www.youtube.com/watch?v=6A9pKXP_lBM
Featuring with industrial-grade IPQ4019/IPQ4029 chipset
Integrated with 2x 2 5G high power Radio module and 2×2 2.4G high power Radio module
Support 4.940GHz to 5.825GHz Frequency Range
Support 2.400GHz to 2.482GHz
Support 2 x 5G MMCX Connectors and 2×2.4G MMCX
Support 5MHz/10MHz/20MHz/40MHz/80MHz Bandwidth
Support 11ABGN/AC
Support fixed data rate
RoHS compliance ensure a high level protection of human health and the environment from risks that can be posed by chemicals
Our Firmware supports all the modules of Quectel
|
Absolute Maximum Rating |
|
Parameter |
Rating |
Unit |
|
Supply Voltage |
24V~48 |
V |
|
Operating Temperature Range |
-40 to +70 |
ºC |
|
Storage Temperature Range |
-45 to +105 |
ºC |
|
Operating Humidity Range |
5 to +95 (non-condensing) |
% |
|
Storage Humidity Range |
0 to +90 (non-condensing) |
% |
|
Hardware Specifications |
|
Symbol |
Parameter |
|
CPU |
IPQ4029（Quad core ARM Cortex A7 at 716.8 MHz） |
|
Antenna Connector |
2 x 5G MMCX connectors;2×2.4G MMCX |
|
10/100/1000Mbps Gigabit Ethernet |
2xRJ45 |
|
SFP connector |
1xSFP fiber module connector (optional) |
|
3G/4G connector |
1xminipcie 3G/4G connector support with two sim card |
|
USB connector |
1xUSB 3.0 connector |
|
POE |
24V~48V passive POE |
|
DC Jack |
24V~48V power supply |
|
ROHS Compliance |
YES |
|
Dimension |
115mm x 105mm x 16mm |
|
Max Power |
48.1V x 0.180A= 8.658W |
|
Nor Flash |
2MB~32MB |
|
Nand Flash |
128MB |
|
DDR |
256MB~512MB |
